Standard PracticesInspection and Maintenance — GEK 107048
SP-51
MS-6001B DLN-1 — Major Inspection Recommended Spare Parts (Cont’d)
Recommended
Quantity
PRIMARY FUEL NOZZLE ASSEMBLY (ML0513) (Cont’d)
**2. Lockplate (Tip Assembly to Body) 50
SECONDARY FUEL NOZZLE ASSEMBLY (ML0566)
1. Outer Gas Tip 10
**2. Lockplate (Outer Tip to Body) 10
3. Piston Ring 10
4. Spiral Wound Gasket (Flame Detector Flange) 10
5. Bolt, Hex Head (Flame Detector Flange) *8
COMBUSTION CHAMBER ARRANGEMENT (ML0701)
**1. Gasket (Cover to Outer Combustion Casing) 10
2. Gasket (Comb. Outer Casing to Compressor Discharge Casing) 10
3. Bolt, Twelve Point Head (Outer Casing to Compressor Discharge Casing) *40*
4. Flow Sleeve, Combustion 10
5. Steel Pan Head Machine Screw (Flow Sleeve Mounting Screws) *16*
6. Ring Packing (Crossfire Tube) 40
7. Bolt, Twelve Point (Nut, Packing Gland) *16*
8. Crossfire Tube Combustion (Male) 10
9. Crossfire Tube Combustion (Female) 10
10. Spring (Crossfire Tube Retainer) 20
**11. Ring, Gasket (Secondary Fuel Nozzle Mounting Flange) 10
12. Bolt, Hex Head (Fuel Nozzle Flange) *16*
**13. Gasket, Pipe Flange (Flame Detector) 8
**14. Gasket, Spiral Wound (Spark Plug) 8
15. Bolt, 12 Point (Flame Detector) *4
