Inspection and Maintenance — GEK 107048Major Inspection — Disassembly Procedures
MI-D-18
Figure MI-D.7. Compressor Discharge and Aft Compressor Casing Supported in Upright Position.
Aft Compressor Casing
(If Applicable)
Compressor Discharge
Casing
NOTE:
Later Vintage Units No Longer Have An
Aft Compressor Case. The Forward and
Aft Casing Have Been Combined and Is
Now Called Compressor Case.
