GE MS-6001B - First-Stage Nozzle Support Ring and Support Groove

Major Inspection — Disassembly ProceduresInspection and Maintenance — GEK 107048
MI-D-15
Figure MI-D.5. First-Stage Nozzle Support Ring and Support Groove.
First Stage Nozzle Support Lug
and Support Pad Seal Groove
First Stage Nozzle With
Support Pad and Support
Pad Retainer
Shim
Inner Barrel Compressor
Discharge Casing
First Stage Nozzle
Support Lug Groove
Offset
Bushing
Hole
First-Stage Universal
Nozzle Support Ring
Shim
Inner Barrel
Compressor Discharge
Casing
Inner Barrel Rabbet
Compressor Discharge Case
