GE MS-6001B - Fuel Nozzle Cleaning Parts Basket; Typical Fuel Nozzle Cleaning and Rinsing Tank

Combustion Inspection — Inspection ProceduresInspection and Maintenance — GEK 107048
CI-I-5
Figure CI-I.4. Fuel Nozzle Cleaning Parts Basket.
Expanded or Perforated
Metal Basket, Preferably
Aluminum
Figure CI-I.5. Typical Fuel Nozzle Cleaning and Rinsing Tank.
Steam
Water
Check
Valve
Check
Valve
Rinse
Nozzle
Insulated
Tank
Stainless Steel
Tank or Double
Sink Apprx. Dim.
12 X 12 X 12 In. Deep
For 5 Gallon Cap
Each Tank.
