GE MS-6001B - Third-Stage Nozzle Seals and Radial Retaining Pins

Hot Gas Path Inspection — Reassembly ProceduresInspection and Maintenance — GEK 107048
HGP-R-9
Figure HGP-R.4. Third-Stage Nozzle Seals and Radial Retaining Pins.
Retaining Pin
3rd Stage
Turbine Wheel
3rd Stage
Nozzle
2 Top 3
Wheel Spacer
Aft Seal
Aft Seal
Axial Seal
Radial Seal
Forward Seal
Forward Seal
Nozzle
Diaphragm
Segment
(View “A–A”)
Holding Plate
and Lockplates
2nd Stage
Turbine Wheel
