Standard PracticesInspection and Maintenance — GEK 107048
SP-49
MS-6001B DLN-1 — Hot Gas Path Inspection Recommended Spare Parts (Cont’d)
Recommended
Quantity
PIPING ARRANGEMENT COOLING AND SEALING AIR (ML0909) (Cont’d)
20. Union Tube 2
21. Union, Tube 4
22. Union, Tube 7
23. Tee, Union Tube 2
24. Nut, Self Locking *5
25. Nut, Self Locking *6
26. Nut, Self Locking *6
NOZZLE ARRANGEMENT, TURBINE FIRST STAGE (ML1401)
1. First Stage Nozzle Arrangement 1
RING RETAINING, TURBINE NOZZLE FIRST STAGE (ML1401)
1. Insert, Wire Locking (Helicoil) 4
2. Insert, Wire Locking (Helicoil) 9
3. Wire, Insert (Helicoil) 30
4. Wire, Insert (Helicoil) 1
SUPPORT RING ASSEMBLY FIRST STAGE NOZZLE (ML1403)
**1. Insert Wire Locking (Helicoil) 18
ENCLOSURE TO BASE ARRANGEMENT (ML1605)
1. Seal, Rubber Strip 2
2. Strip 1
3. Gasket, Silicone 1
4. Gasket, Dryback Adhesive 1
5. Gasket, Asbestos 1
6. Screw, Machine Round Head (#10-24 x 0.750) *5
7. Washer, Plain Regular (.375 Steel Plain Washer) *20*
8. Bolt, Hex Head (.375-16 x 3.50) *15*
9. Washer, Rubber *16*
10. Bolt, Hex Head (.375-16 x 2.50) *4
11. Lockwasher, Spring (.625 Steel Spring Lockwasher) *12*
12. Bolt, Hex Head (.625-11 x 2.00) *4
13. Nut, Hexagon (.625-11) *8
14. Bolt, Hex Head (.250-20 x 0.750) *8
BOLTING AND DOWELING ARRANGEMENT (ML1604)
1. Bolt, Twelve Point Head (Compressor Discharge Casing to Turbine Casing) *8
