Combustion Inspection — Inspection ProceduresInspection and Maintenance — GEK 107048
CI-I-25
Figure CI–I.12. Flow Sleeve.
Mounting
Cutout For
Crossfire Tube
(2)
Cutout For
Liner Stop
Flange
Machine
Screws
Figure CI–I.13. Combustion Outer Casing.
Liner
Stop
Crossfire/Retainer
Boss–Ref.
Recess For
Flow Sleeve
Flange
