Combustion Inspection — Reassembly ProceduresInspection and Maintenance — GEK 107048
CI-R-17
Figure CI–R.14. Spark Plug Assembly.
Tubine Fitting
for Adjustment
of Insertion
Ball Joint
Packing
Igniter Assembly
Base Assembly
Flow
Sleeve
Casing
Flange
Liner
Igniter Assembly
0.38
Packing
Bolt
Packing
Bolt
Mounting Bolt
