850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 4–1
850 Feeder Protection System
Chapter 4: Setpoints
GE
Grid Solutions
Setpoint s
Setpoints Main Menu
The 850 has a considerable number of programmable setpoints, all of which make the
relay extremely flexible. These setpoints have been grouped into a variety of menus which
are available from the paths shown below. Each setpoints menu has sub-sections that
describe in detail the setpoints found on that menu.
NOTE:
Use the path provided to access the menus from the front panel and from the EnerVista 8
Series Setup software.
NOTE:
For certain named settings the user may configure custom names. The user should not
create 13-character long names using the largest width characters (i.e.
WWWWWWWWWWWWW). Doing so can cause the last 3 characters to overlap the
setting name when viewed from the HMI or the PC program.
