POWER DEMAND CHAPTER 6: METERING
Power Demand
This menu shows the real, reactive, and apparent power demands along with their
maximums. The maximums can be cleared by resetting them from Records \Clear Records
\Max Real /Reactive /Apparent Demand.
Path: Metering > Power Demand 1(X)
Reset (Reset Dmd Date/Time) MM/DD/YY 00:00:00
Real Demand (Real Dmd)
Range: 0.0 kW to 214748364.7 kW
Maximum Real Demand (Max Real Dmd)
Range: 0.0 kW to 214748364.7 kW
Date/Time Real Demand (Date/Time Real Dmd) MM/DD/YY 00:00:00
Reactive Demand (Reactive Dmd)
Range: 0.0 kvar to 214748364.7 kvar
Maximum Reactive Demand (Max Reactive Dmd)
Range: 0.0 kvar to 214748364.7 kvar
Date/Time Reactive Demand (Date/Time Reactive Dmd) MM/DD/YY 00:00:00
Apparent Demand (Apparent Dmd)
Range: 0.0 kVA to 214748364.7 kVA
Maximum Apparent Demand (Max Apparent Dmd)
Range: 0.0 kVA to 214748364.7 kVA
Date/Time Apparent Demand (Date/Time Apparent Dmd) MM/DD/YY 00:00:00
Thermal Capacity
The menu displays the thermal capacity values in percentage format. These values can be
cleared by the command in RECORDS \ CLEAR RECORDS\ THERMAL CAPACITY.
Path: Metering > Thermal Capacity
Phase A Thermal Capacity (Phase A Thermal 1[X] Cap) 0.0 %
Range: 0.0 to 100.0 %
Phase B Thermal Capacity (Phase B Thermal 1[X] Cap) 0.0 %
Range: 0.0 to 100.0 %
Phase C Thermal Capacity (Phase C Thermal 1[X] Cap) 0.0 %
Range: 0.0 to 100.0 %
