CHAPTER 5: STATUS LAST TRIP DATA
850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 5–5
Last Trip Data
The Last Trip Data feature stores the same 64 FlexAnalog quantities that are configured for
the Event Data. Last Trip Data has a ‘Clear Last Trip Data’ command that clears the Last
Trip Data storage.
The “Event Number of Last Trip” value contains the number of the last event of a Trip type.
This is a platform feature and a ‘Basic’ option so it has no dependencies.
There is no Enabling/Disabling of this feature. It is always ‘ON’.
When changes are made to the Event Data settings, the Last Trip Data is cleared and the
LastTrip.txt file is deleted.
Path: Status > Last Trip Data
CAUSE
Range: Off, any FlexLogic Operand
Default: No trip to Date
EVENT
Range: 0 to 4294967295 in steps of 1
Default: 0
DATE
Range: MM/DD/YYYY HH:MM
Default: 01/01/08 00:00:00
PARAMETER 1 to 64
Range: -2147483648 to 2147483647 in steps of 1
Default: 0
Arc Flash
Path: Status > Arc Flash > Arc Flash 1
The status value shows the state of the given Flex operand related to Arc Flash protection.
Light 1(4) PKP
Range: ON, OFF
HS Phase IOC PKP A/B/C
Range: ON, OFF
HS Ground IOC PKP
Range: ON, OFF
Arc Flash OP
Range: ON, OFF
