GE Multilin 850

1–10 850 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL
850 ORDER CODES CHAPTER 1: INTRODUCTION
FAST PATH:
Harsh Environment Coating is a standard feature on all 8 Series units.
Advanced security is only available with advanced communications (1E, 1P, 2A, 2E, 3A, 3E).
When the advanced communications option is selected, the Ethernet port on the main CPU
is disabled.
FAST PATH:
Retrofit order codes must be configured using the GE Multilin Online Store (OLS) based on
the existing relay order code and additional requirements.
Navigate to https://www.gegridsolutions.com/multilin/catalog/850.htm
and click Buy
Retrofit Kit for further information.
Accessories
• 18J0-0030 8 Series Depth Reducing Collar - 1 3/8"
• 18J0-0029 8 Series Depth Reducing Collar - 3"
• 8 Series Retrofit Kit, 750/760 to 850
• 8 Series Retrofit Kit, 735 to 850
892800A5.PDF
Communications S E
|
|
|
|
|
|
|
|
|
|
Standard: Front USB, 1 x Rear RS485: Modbus RTU, DNP3.0,
IEC60870-5-103 + 1 x Ethernet (Modbus TCP, DNP)
1 E
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Advanced: Front USB, 1 x Rear RS485 + 2 x Ethernet Fiber,
MODBUS RTU/TCP, DNP3.0, IEC 60870-5-103/104, 1588,
SNTP, OPC-UA
1 P | | | | | Advanced + PRP
2 A
|
|
|
|
|
|
|
|
|
|
Advanced + IEC 61850
2 E | | | | | Advanced + PRP + IEC 61850
3 A
|
|
|
|
|
|
|
|
|
|
Advanced + Extended IEC 61850
3 E | | | | | Advanced + PRP + Extended IEC 61850
Advanced Communications Connector N |||| None
S|||| ST, Multi-mode 1310 nm
C|||| RJ45, Copper 10/100 M
Wireless Communication N | | | None
W | | | WiFi 802.11
Security B| | Basic
A| | Advanced: CyberSentry Level 1
Future Option N | Not Available
Retrofit Kit Option 1
Wye 750-850 Retrofit Kit, terminal block wiring assembly
for wye (for retrofit kit only)
2
Delta 750-850 Retrofit Kit, terminal block wiring assembly
for delta (for retrofit kit only)
3
Wye 735-850 Retrofit Kit, terminal block wiring assembly
for wye (for retrofit kit only)
4
Delta 735-850 Retrofit Kit, terminal block wiring assembly
for delta (for retrofit kit only)
850  * * NN * * * * A * * * * * * * * * * * * N *
