Tab Pushbuttons TAB PB [X] ON
TAB PB [X] OFF
TAB PB [X] PRESS
Tab Pushbutton [X] is ON
Tab Pushbutton [X] is OFF
Tab Pushbutton [X] is Pressed Down
Thermal Overload Thermal 1 Alarm A
Thermal 1 Alarm B
Thermal 1 Alarm C
Thermal 1 Alarm
Thermal 1 PKP A
Thermal 1 PKP B
Thermal 1 PKP C
Thermal 1 PKP
Thermal 1 OP A
Thermal 1 OP B
Thermal 1 OP C
Thermal 1 OP
Thermal 2 Alarm A
Thermal 2 Alarm B
Thermal 2 Alarm C
Thermal 2 Alarm
Thermal 2 PKP A
Thermal 2 PKP B
Thermal 2 PKP C
Thermal 2 PKP
Thermal 2 OP A
Thermal 2 OP B
Thermal 2 OP C
Thermal 2 OP
Phase A of thermal overload 1 produced alarm
Phase B of thermal overload 1 produced alarm
Phase C of thermal overload 1 produced alarm
At least one phase of thermal overload 1 produced alarm
Phase A of thermal overload 1 has picked up
Phase B of thermal overload 1 has picked up
Phase C of thermal overload 1 has picked up
At least one phase of thermal overload 1 has picked up
Phase A of thermal overload 1 has operated
Phase B of thermal overload 1 has operated
Phase C of phase thermal overload 1 has operated
At least one phase of thermal overload 1 has operated
Phase A of thermal overload 2 produced alarm
Phase B of thermal overload 2 produced alarm
Phase C of thermal overload 2 produced alarm
At least one phase of thermal overload 2 produced alarm
Phase A of thermal overload 2 has picked up
Phase B of thermal overload 2 has picked up
Phase C of thermal overload 2 has picked up
At least one phase of thermal overload 2 has picked up
Phase A of thermal overload 2 has operated
Phase B of thermal overload 2 has operated
Phase C of phase thermal overload 2 has operated
At least one phase of thermal overload 2 has operated
Timed Undervoltage Timed UV PKP
Timed UV PKP A
Timed UV PKP B
Timed UV PKP C
Timed UV OP
Timed UV OP A
Timed UV OP B
Timed UV OP C
Timed UV Curve OP
Timed UV Cnt OP
At least one phase of the Timed Undervoltage curve has picked up
Phase A of Timed Undervoltage has picked up
Phase B of Timed Undervoltage has picked up
Phase C of Timed Undervoltage has picked up
Timed Undervoltage has operated
Phase A of Timed Undervoltage has operated
Phase B of Timed Undervoltage has operated
Phase C of Timed Undervoltage has operated
At least one phase of Timed Undervoltage curve has operated
Timed Undervoltage counter has operated
Trip Bus Trip Bus 1 PKP
Trip Bus 1 OP
Trip Bus 2 to 6
Asserted when the trip bus 1 element picks up
Asserted when the trip bus 1 element operates
The same set of operands as per Trip Bus 1
Trip Circuit Monitoring TripCoil Mon 1 PKP
TripCoil Mon 1 OP
Trip Coil 1 Monitoring element has picked up.
Trip Coil 1 Monitoring element has operated for an amount of time greater
than the Close Circuit Monitor Pick-up Delay Time.
Undercurrent Undercur[X] Alarm PKP
Undercur[X] Alarm OP
Undercur[X] Trip PKP
Undercur[X] Trip OP
Undercurrent[X] Alarm has picked up.
Undercurrent[X] Alarm has operated.
Undercurrent[X] Trip has picked up.
Undercurrent[X] Trip has operated.
Undervoltage Restoration UV Restore Init
Ph UV Restore PKP
Ph UV Restore OP
Aux UV Restore PKP
Aux UV Restore OP
Undervoltage restoration element has been initiated
Phase voltage of undervoltage restoration has element picked up
Phase voltage of undervoltage restoration element has operated
Auxiliary voltage of undervoltage restoration has element picked up
Auxiliary voltage of undervoltage restoration element has operated
Underfrequency
Restoration
UF Restore PKP
UF Restore OP
UF Restore Init
Under-frequency restoration has element picked up
Under-frequency restoration element has operated
Under-frequency restore initiate flag is high
UnderFrequency Underfreq 1 PKP
Underfreq 1 OP
Underfreq 2 to 4
Underfrequency 1 has picked up
Underfrequency 1 has operated
The same set of operands as per Underfreq 1
UV Reactive Power UV Var PKP
UV Var OP
UV Var Restore
UV Reactive Power Trip has picked up
UV Reactive Power Trip has operated
Circuit breaker re-closing command is asserted
Virtual Input 1 to 32 VI # ON
VI # OFF
# – any virtual input number
