GE PACE Series

PACE Series SCPI Manual
K0472 Revision A 4-15
:INST:CONT:SENS
Applicability: PACE5000 and PACE6000
Command Syntax
n/a
Parameter:
Short form:
Function:
Query Syntax
:INSTrument(x):CONTroller(y]:SENse(z)
:Inst(x):Cont(y):Sens(z)?
INSTindex(x)wherexmustbe0or‘blank’
UsetheCONTindex(y)todeterminewhichcontrolmodule1(orblank)or2.Both:Inst:Contand
:Inst:Cont1willaddresscontrolmodule1,whilst:Inst:Cont2addressesonlycontrolmodule2.
UsetheSENSindex(z)todeterminewhichsensorasbelow.
Description
:INST:CONT:SENSor:INST:CONT:SENS1"2.00barg"returnsControlmodule1full‐scalerange
sensor
:INST:CONT:SENS2"7.00barg"returnsthe+veportsourcepressuresensorfull‐scale
:INST:CONT:SENS3"1.00barg"returnsthe–veportvacuumpressuresensorfull‐scale
:INST:CONT:SENS4"BAROMETER"
:INST:CONT:SENS5""Referencesensorrangeiffitted
:INST:CONT:SENS6""Notused
:INST:CONT:SENS7"3.00bara"Returnsthepseudoabsoluterange
:INST:CONT:SENS8 "" Not used
Example
TX> :Inst:Cont1:Sens2?
RX> :INST:CONT1:SENS2 "7.00barg" 1st control module vacuum sensor
TX> :Inst:Cont2:Sens4?
RX> :INST:CONT2:SENS4 "BAROMETER" 2nd control module barometric sensor
