PACE Series SCPI Manual
K0472 Revision A 4-23
INST:SENS:NEG
Applicability: PACE1000, PACE5000, PACE6000
Command Syntax
n/a
Parameter:
Short form:
Function:
Query Syntax
:INSTrument:SENSor[x]:NEGCal?
where: x = 1, 2…8 is the sensor number. It defaults to 1.
Short form: :INST:SENS:NEG?
Function: Queries sensor negative calibration.
Response: <boolean>: 0 - negative calibration not supported
1 - negative calibration supported.
Description
This command query returns sensor negative calibration supported or not supported. Used
in DPI515 emulation; for PACE5000/6000 this query always returns ‘1’.
x SensorPACE5000, PACE6000 PACE1000 x SensorPACE5000, PACE6000 PACE1000
1 Module 1: control sensor
Internal
sensor1
5 Module 2: control sensor
External
IDOS-2
2 Module 1: source pressure +ve
Internal
sensor 2
6 Module 2: source pressure +ve
External
IDOS-3
3 Module 1: source pressure -ve
Internal
sensor 3
7 Module 2: source pressure -ve -
4
Module 1: barometric range
(optional)
External
IDOS-1
8
Module 2: barometric range
(optional)
-
:INST:SENS:NEGC?
:INST:SENS:NEGC 1
Default - module 1 control sensor NEGcal.
:INST:SENS5:NEGC?
:INST:SENS5:NEGC 1
Returns module 2 control sensor NEGcal.
:INST:SENS1:NEGC?
:INST:SENS:NEGC 1
Returns module 1 control sensor NEGcal.
:INST:SENS6:NEGC?
:INST:SENS2:NEGC 1
Returns module 2 +ve source sensor NEGcal.
:INST:SENS2:NEGC?
:INST:SENS2:NEGC 1
Returns module 1 +ve source sensor NEGcal.
:INST:SENS7:NEGC?
:INST:SENS7:NEGC 1
Returns module 2 -ve source sensor NEGcal.
:INST:SENS3:NEGC?
:INST:SENS3:NEGC 1
Returns module 1 -ve source sensor NEGcal.
:INST:SENS8:NEGC?
:INST:SENS8:NEGC 1
Returns module 2 barometric sensor NEGcal.
:INST:SENS4:NEGC?
:INST:SENS4:NEGC 1
Returns module 1 barometric sensor NEGcal.
