PACE Series SCPI Manual
K0472 Revision A 3 - 9
Status reporting register structure
To set-up the status reporting system.
1 All status registers should be cleared by the command:
*CLS
2 The Pressure Operations Event register has to be set to enable the Pressure Operations
Condition Register to send all the events to be reported; use the command:
:STAT:OPER:PRES:ENAB 511
The enabled events may also be read by the query:
:STAT:OPER:PRES:ENAB?
3 The Operation Status Event register must then be enabled to read bit 10 by the
command:
:STAT:OPER:ENAB 1024
The enabled events may also be read by the query:
:STAT:OPER:ENAB?
4 The status request to enable the SRQ must then be set.
To enable only the Operation Status register (OSB) send the command:
*SRE 128
To enable the Operation Status register (OSB) and the Error Queue (EAV) send the
command:
*SRE 132
This register may also be read by the query:
*SRE?
An event occurring generates an SRQ, the Status Byte should be queried to find the
source of the event.
