PACE Series SCPI Manual

K0472 Revision A 4-15

:INST:CONT:SENS

Applicability: PACE5000 and PACE6000

Command Syntax

n/a

Parameter:

Short form:

Function:

Query Syntax

:INSTrument(x):CONTroller(y]:SENse(z)

:Inst(x):Cont(y):Sens(z)?

INSTindex(x)wherexmustbe0or‘blank’

UsetheCONTindex(y)todeterminewhichcontrolmodule1(orblank)or2.Both:Inst:Contand

:Inst:Cont1willaddresscontrolmodule1,whilst:Inst:Cont2addressesonlycontrolmodule2.

UsetheSENSindex(z)todeterminewhichsensorasbelow.

Description

:INST:CONT:SENSor:INST:CONT:SENS1"2.00barg"returnsControlmodule1full‐scalerange

sensor

:INST:CONT:SENS2"7.00barg"returnsthe+veportsourcepressuresensorfull‐scale

:INST:CONT:SENS3"1.00barg"returnsthe–veportvacuumpressuresensorfull‐scale

:INST:CONT:SENS4"BAROMETER"

:INST:CONT:SENS5""Referencesensorrangeiffitted

:INST:CONT:SENS6""Notused

:INST:CONT:SENS7"3.00bara"Returnsthepseudoabsoluterange

:INST:CONT:SENS8 "" Not used

Example

TX> :Inst:Cont1:Sens2?

RX> :INST:CONT1:SENS2 "7.00barg" 1st control module vacuum sensor

TX> :Inst:Cont2:Sens4?

RX> :INST:CONT2:SENS4 "BAROMETER" 2nd control module barometric sensor
