GE SecoGear Application Guide

SecoGear Medium-voltage Switchgear Application and Technical Guide DET-882
SecoGear Switchgear Concepts and Basic Configurations
4 ©2017 General Electric All Rights Reserved
Figure 1-5: Dual VT Rollouts, Line/Bus Connected –
Upper or Lower Section
Figure 1-6: Dual CPT Rollouts, Line/Bus Connected –
Upper or Lower Section
Figure 1-7: 1200 A/2000 A – Upper or Lower
Breaker Section
Figure 1-8: VT Rollout, Line/Bus Connected and Fuse
Rollout, Line Connected – Lower Section
VT
VT
CPT
CPT
Space for 4 CTs per phase:
• 2 on upper studs
• 2 on lower studs
Breaker
VT
Fuse Rollout
