DET-882 SecoGear Medium-voltage Switchgear Application and Technical Guide
SecoGear Switchgear Concepts and Basic Configurations
©2017 General Electric All Rights Reserved 7
Figure 1-15: Breaker in Compartment A, Line- and Bus-
connected VT Rollouts in Compartment B
Figure 1-16: Breaker in Compartment B, Bus-connected
VT Rollout in Compartment A
Figure 1-17: Breaker in Compartment B, Bus-connected
CPT in Compartment A
Figure 1-18: Bus Entry in Compartment A – Cabling
Above, Breaker in Compartment B – Cabling Below
Breaker
VT
A
B
CTs
VT
Breaker
A
B
CTs
VT
Breaker
A
B
CTs
CPT
Breaker
A
B
CTs
