DET-882 SecoGear Medium-voltage Switchgear Application and Technical Guide
Circuit Breaker Selection
©2017 General Electric All Rights Reserved 15
Figure 2-3: SecoVac VB2+ Breaker Front Panel
Figure 2-4: Spring Discharge Instructions
Open pushbutton
Spring discharge
instructions
Breaker
nameplate
Spring charge
status indicator
HV warning label
Open/close
indicator
Close pushbutton
Secondary disconnect
plug connector
Vacuum bottle
label
Operation
counter
Charging handle

Table of Contents
