Handling and assembly
Tool bar assembly (optional)
2018-9015-001
09-2016
73 / 192
5.22.4 Tool bar with 22'' concave disc incorporators
1
2
3
● Bolt the tool bar (1) to the spreader frame (2) using provided hardware;
● Connect the hydraulic cylinder to the tool bar (1);
● Install safety chains (3);
● Assemble the tool as illustrated above;
