Handling and assembly
Tool bar assembly (optional)
2018-9015-001
09-2016
74 / 192
1
5
4
6
● Install the tools (4) on the tool bar (1);
● Install a hose (5) from the spreader distributor to the tool (4);
● Cut the hose (5) at proper length. The hose (5) should not be tight, keep a
loose;
● Fix the hose (5) to the tool (4) using a collar (6);
● Repeat these steps for each tool (4);
● Connect hydraulic hoses to the spreader.
