valve does not hold the lift am and it begins to lower do not leave the operator’s
compartment. Instead, lower the lift arm and exit the machine. Then, contact
your Gehl dealer immediately to determine why the lift arm lowers while the key
switch is OFF.
To return the lift arm support device to its
storage position:
1. Start the engine.
2. Raise the lift arm fully.
3. Stop the engine.
4. Verify that the lift arm is being held in
the raised position by the safety inter-
lock system.
5. To store the support device, have an
assistant raise it up until it contacts the
lift arm. Reinstall the lynch pin
through the welded steel post on the
lift arm (Figure 5).
Accessory Plug
The 12-V accessory plug is located at the bottom of the right instrument panel.
Dome Light
The dome light is located on the left side of the ROPS/FOPS headliner. Push on
the dome light to switch it on.
Work Lights
Loaders have two sets of work lights. The front work lights are located at the top
of the ROPS/FOPS. The rear work lights are located at the top of the rear grille.
Heater (optional)
Loaders with the optional heater have two control knobs on top of the heater unit
for controlling fan speed and heater temperature.
1. Fan Speed Control Knob: Controls the fan speed and turns the heater sys-
tem on or off.
2. Temperature Control: The rotary knob regulates the temperature of the
heated air. Rotate clockwise to increase the temperature; counterclockwise to
decrease the temperature.
Figure 5 Lock Pin
in storage Position
