50950260/AP1216 33
Attachment Mounting
The Gehl loader is equipped with a
two-pin All-Tach™ attachment bracket
for mounting a bucket or other attach-
ment. Two latch levers secure the attach-
ment. Rotate the levers until they are hori-
zontal to engage the latch pins. Rotate the
levers until they are vertical to disengage
the latch pins.
To prevent unexpected release of the attach-
ment from the hitch, be sure to secure the latch
pins by rotating the levers all the way to the hitch.
Electrical Battery Disconnect Switch (optional)
An optional electrical battery disconnect
switch is located inside the engine com-
partment on the left side and forward of
the fuse panel. Turn the switch to the OFF
position to disconnect the battery from the
electrical system.
Figure 15 All-Tach™
Attaching Mechanism (Hitch)
Figure 16 Battery Disconnect
Switch
