50950260/AP1216 51
Servo Whole-Body and Hand-Arm Vibration Levels*
*Whole-Body Vibration levels in accordance with ISO 2631-1. Hand-Arm Vibration levels in
accordance with ISO 5349-1.
Highway Travel
If it becomes necessary to move the loader a long distance, use a properly rated
trailer. (See “Transporting/Towing the Loader” on page 54.) For short distance
highway travel, attach an SMV (Slow-Moving Vehicle) emblem (purchased
locally) to the back of the loader. For highway operation, install the optional
amber strobe light. Check state and local laws and regulations.
Seat Option
Servo Whole-Body Servo Hand-Arm
Vibration
m/s
2
Uncertainty
m/s
2
Vibration
m/s
2
Uncertainty
m/s
2
Mechanical
Suspension
1.24 0.62 1.80 0.90
Standard
Non-Suspen-
sion
1.12 0.56 1.70 0.85
