82 50950260/AP1216
Checking Tire Pressure
Correct tire pressure should be maintained for all tires to enhance operating
stability and extend tire life. Refer to the above chart for the proper inflation
pressure.
When installing tires, be sure they are the same size and style on each side of the
loader. Always replace tires with the same size as the original equipment.
Electrical System
Battery
Before servicing the battery or electrical
system, be sure the battery disconnect switch
(if equipped) is in the “OFF” position. If not equipped with a discon-
nect switch, disconnect the ground (-) terminal from battery.
The battery on the loader is a 12-volt, wet-cell battery. To access the battery, open
the rear door and lift the engine cover.
The battery top must be kept clean. Clean it with an alkaline solution (ammonia
or baking soda and water). After foaming has stopped, flush the battery top with
clean water. If the terminals and cable connection clamps are corroded or have a
build-up, disconnect the cables and clean the terminals and clamps with the same
alkaline solution.
Explosive gas is produced while a battery is in
use or being charged. Keep flames or sparks
away from the battery area. ALWAYS charge the battery in a well-
ventilated area.
Never lay a metal object on top of a battery, because a short circuit
can result.
Battery acid is harmful on contact with skin or fabrics. If acid spills,
follow these first-aid tips:
1. Immediately remove any clothing on which acid spills.
Tire Size
Inflation Pressure
psi kPa
10 x 16.5 8-ply Heavy-Duty Flotation 60 414
27 x 8.5 –15 8-ply Heavy-Duty 60 414
27 x 10.5 – 15 8-ply Heavy-Duty 60 414
6.5 x 16 – 5.50 Solid Rubber - -
7.00-15 SS Chevron Narrow 8-ply 60 414
