Gehl R105 X-Series User Manual

50950260/AP1216 85
CHAPTER 6
TROUBLESHOOTING
Electrical System
Problem Possible Cause Corrective Action
Electrical system does
not function
Battery disconnect switch is in
OFF position.
Turn battery disconnect switch
to the ON position.
Battery terminals or cables
loose or corroded.
Clean battery terminals and
cables and retighten.
Battery malfunction.
Test battery. Recharge/
replace as necessary.
Blown main fuse.
Correct over-current problem
and replace main fuse.
Main wiring harness connectors
at rear of ROPS/FOPS not
properly plugged in.
Check main harness
connectors. Reconnect/repair
as needed.
Control pad and
information center
display do not activate
with ignition keyswitch in
the ON/RUN position
Blown fuse. Check circuit and replace fuse.
Battery terminals/cables
loose/corroded.
Clean battery terminals and
cables and tighten.
Main wiring harness connectors
at rear of ROPS/FOPS not
properly plugged in.
Check main harness
connectors. Reconnect/repair
as needed.
Starter does not engage
when ignition keyswitch
turned to the START
position
Poor electrical connections in
start circuit.
Check connections repair as
necessary.
Battery terminals/cables
loose/corroded.
Clean battery terminals and
cables and tighten.
Starter relay malfunction.
Test relay; replace if necessary.
Contact dealer.
Battery
discharged/malfunctioning.
Test battery. Recharge/
replace if necessary.
Starter solenoid malfunction. Contact dealer.
Starter or pinion malfunctioning. Repair/replace as needed.
Ignition wiring, seat switch,
restraint bar switch, etc. loose
or disconnected.
Check wiring for poor
connections, broken leads;
repair wiring or connection.
Restraint bar raised. Lower restraint bar.
Engine fault code(s). Contact dealer.
