138 50940193/DP0415
7. Prime the fuel system by turning the ignition key to the ON position without starting
the engine for 30 seconds. Repeat this step 3 times to ensure the fuel system is
completely primed.
Do not use the starter motor to crank the engine to
prime the fuel system. Damage to the engine
starter motor, coils, pinion/ring gear could result.
8. Start the engine and check for leaks.
Changing Fuel Filter
NEVER service the fuel system while smoking,
while near an open flame, or if the engine is hot.
Important: Change the fuel filter every 250 hours of operation.
1. Perform the “Mandatory Safety Shutdown Procedure” on page 14.
2. Wait until the engine has cooled.
3. Turn fuel valve lever (V, Figure 99) on the
water separator to the OFF position.
4. Remove the fuel filter (W, Figure 100),
using a filter wrench if necessary.
Carefully clean the filter head mounting
surface with a clean cloth.
5. Apply a coating of clean diesel fuel on the
new fuel filter gasket. Install the filter and
tighten 3/4 rotation past the point where
the gasket contacts the filter head.
6. Turn fuel valve (V, Figure 99) on the
water separator to the ON position.
7. Prime the fuel system by turning the
ignition key to the ON position without starting the engine for 30 seconds. Repeat this
step 3 times to ensure the fuel system is completely primed.
Figure 99 – Water Separator
V
Figure 100 – Fuel Filter
W
