Gehl R135 User Manual

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Safety Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Indicators and Controls. . . . . . . . . . . . . . . . . . . . . . . . . . 47
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
R135, R150, R165 Skid-Steer Loader
Operator’s Manual
TABLE OF CONTENTS
LOADER INFORMATION
Purchased from
Date of Purchase
Loader Model Number
Loader Serial Number
Engine Serial Number

Gehl R135 Specifications

General

Operating Capacity	1350 lbs
Tipping Load	2700 lbs
Rated Operating Capacity (SAE)	1350 lbs
Engine Make	Yanmar
Rated Operating Capacity (kg)	612 kg
Tipping Load (kg)	1225 kg
Fuel Tank Capacity	16 gal
Net Power	46 hp
Fuel Capacity	16 gal
