Gehl R135 User Manual

101 50940193/DP0415
Self-Leveling (Option)
Self-leveling automatically keeps the tilt angle
of the attachment constant, relative to the
ground plane, when the lift arm is raised (A,
Figure 68). This feature is especially useful
when using pallet forks.
Important: Self-leveling operates only when
the lift arm is raised: when the lift arm is
lowered (B), self-leveling is not activated.
Note: Self-leveling is activated by default. To
deactivate self-leveling, see “Self-Leveling
Cancel” on page 102.
Figure 68 – Self-Leveling
Operation
Self-Leveling
Operates When Lift
Arm is Raised
A
Self-Leveling Does
Not Operate When
Lift Arm is Lowered
A
A
B
B
B

Gehl R135 Specifications

General

Operating Capacity	1350 lbs
Tipping Load	2700 lbs
Rated Operating Capacity (SAE)	1350 lbs
Engine Make	Yanmar
Rated Operating Capacity (kg)	612 kg
Tipping Load (kg)	1225 kg
Fuel Tank Capacity	16 gal
Net Power	46 hp
Fuel Capacity	16 gal
