130
129
U
3 / 4
EX_BYP_VOLT1
Bypass Voltage Phase 2
in V
1
130
U
3 / 4
EX_BYP_VOLT2
Bypass Voltage Phase 3
in V
1
131
U
3 / 4
EX_BYP_CURR0
Bypass Current Phase 1 in
A
1
132
U
3 / 4
EX_BYP_CURR1
Bypass Current Phase 2 in
A
1
133
U
3 / 4
EX_BYP_CURR2
Bypass Current Phase 3 in
A
1
134
U
3 / 4
EX_BYP_WATT0
Bypass Watt Phase 1
1
135
U
3 / 4
EX_BYP_WATT1
Bypass Watt Phase 2
1
136
U
3 / 4
EX_BYP_WATT2
Bypass Watt Phase 3
1
Section MHD Modular
Multimatic
Modular
AEG Protect 1.
Modular, ENIGMA
100
U
3 / 4
OUTPOWER0
Outpower Phase 1 %
1
101
U
3 / 4
OUTPOWER1
Outpower Phase 2 %
1
102
U
3 / 4
OUTPOWER2
Outpower Phase 3 %
1
103
U
3 / 4
BATTCAP
Battery Capacity %
1
104
S
3 / 4
INVOLT0
Input Voltage Phase 1 V
1
105
S
3 / 4
INVOLT1
Input Voltage Phase 2 V
1
106
S
3 / 4
INVOLT2
Input Voltage Phase 3 V
1
107
S
3 / 4
TEMPDEG
Temperature C°
1
108
S
3 / 4
AUTONOMTIME
Autonomy Time minutes
1
109
U
3 / 4
STATUS (e. g. UPS normal =
"4", Powerfail = "12", Battery
test running = "68", Bypass =
"5")
UPS Status (ASCII HEX), please
note UPSMAN status bytes table
below
1
110
U
3 / 4
BATTVOLT
Battery Voltage V
1
111
U
3 / 4
INFREQ0
Input Frequency Hz Phase 1
1
112
U
3 / 4
INFREQ1
Input Frequency Hz Phase 2
1
113
U
3 / 4
INFREQ2
Input Frequency Hz Phase 3
1
114
U
3 / 4
CNT_PF
Powerfail Counter
1
115
U
3 / 4
(SNMPALARMS&0x1)
Alarm Battery Bad
1
116
U
3 / 4
(SNMPALARMS&0x2)>>1
Alarm: On Battery
1
