Generex CS121L - Page 137

135
199
U
3 / 4
AEESerModuleCurr(1)
Status data, for details please
contact Effekta directly
1
200
U
3 / 4
AEESerModuleCurr(2)
Status data, for details please
contact Effekta directly
1
201
U
3 / 4
AEESerModuleCurr(3)
Status data, for details please
contact Effekta directly
1
202
U
3 / 4
AEESerModuleCurr(4)
Status data, for details please
contact Effekta directly
1
203
U
3 / 4
AEESerModuleCurr(5)
Status data, for details please
contact Effekta directly
1
204
U
3 / 4
AEESerModuleCurr(6)
Status data, for details please
contact Effekta directly
1
Section Inform
UPS
Pyramid DSP/Online
DSP
Standard UPS values plus the
following
151
U
3 / 4
OUTPUT_VOLT0
Outputvoltage Phase 1
1
152
U
3 / 4
OUTPUT_VOLT1
Outputvoltage Phase 2
1
153
U
3 / 4
OUTPUT_VOLT2
Outputvoltage Phase 3
1
154
U
3 / 4
OUTPUT_CURRENT0
Output Current Phase 1 in Ampere
*10
1
155
U
3 / 4
OUTPUT_CURRENT1
Output Current Phase 2 in Ampere
*10
1
156
U
3 / 4
OUTPUT_CURRENT2
Output Current Phase 3 in Ampere
*10
1
Section
Transfer Switches
All transfer switch vendors, except PILLER
1
U
3 / 4
Sources Asynchronous
Warning, input current difference, switching might
not be possible
1
2
U
3 / 4
Static Switch A Failure
Alarm, switching failure
1
3
U
3 / 4
Static Switch B Failure
Alarm, switching failure
1
4
U
3 / 4
On Static Switch A
Supplied from input A
1
5
U
3 / 4
On Static Switch B
Supplied from input B
1
6
U
3 / 4
On Manual Bypass A
Supplied via bypass from input A
1
7
U
3 / 4
On Manual Bypass A
Supplied via bypass from input B
1
8
U
3 / 4
Source A Failure
Alarm, input A failure, problem with voltage
1
9
U
3 / 4
Source B Failure
Alarm, input B failure, problem with voltage
1
10
U
3 / 4
General Fault
General alarm
1
11
U
3 / 4
Redundancy Lost
Redundancy lost,
1
12
U
3 / 4
Output Overload
To much load
1
13
U
3 / 4
Output Failure
Output failure
1
