Generex CS121L - Page 138

136
Section
STS TUMEL
Transfer Switch
100
U
3 / 4
INPVOLT_NET_10
Input Voltage
1
101
U
3 / 4
INPVOLT_NET_11
Input Voltage
1
102
U
3 / 4
INPVOLT_NET_12
Input Voltage
1
103
U
3 / 4
INFREQ_NET_1
Input Frequency
1
104
U
3 / 4
INPVOLT_NET_20
Input Voltage
1
105
U
3 / 4
INPVOLT_NET_21
Input Voltage
1
106
U
3 / 4
INPVOLT_NET_22
Input Voltage
1
107
U
3 / 4
INFREQ_NET_2
Input Frequency
1
108
U
3 / 4
STS_SYNCANGLE
1
109
U
3 / 4
STS_SYNDIFF
1
110
U
3 / 4
STS_S1BALANCE
1
111
U
3 / 4
STS_S2BALANCE
1
112
U
3 / 4
TEMPDEG
Temperature in degrees C°
1
113
U
3 / 4
OUTPUT_VOLT0
Output Voltage Phase 1
1
114
U
3 / 4
OUTPUT_VOLT1
Output Voltage Phase 2
1
115
U
3 / 4
OUTPUT_VOLT1
Output Voltage Phase 3
1
116
U
3 / 4
EX_OUT_CURR0
1
117
U
3 / 4
EX_OUT_CURR1
1
118
U
3 / 4
EX_OUT_CURR2
1
119
U
3 / 4
OUTPOWER0
Output Power Phase 1
1
120
U
3 / 4
OUTPOWER1
Output Power Phase 2
1
121
U
3 / 4
OUTPOWER2
Output Power Phase 3
1
Section
OEM
Trimod
100
U
3 / 4
OUTPOWER0
Outpower Phase 1 %
1
101
U
3 / 4
OUTPOWER1
Outpower Phase 2 %
1
102
U
3 / 4
OUTPOWER2
Outpower Phase 3 %
1
103
U
3 / 4
BATTCAP
Battery capacity in percent
1
104
U
3 / 4
INVOLT0
Input Voltage Phase 1 in V
1
105
U
3 / 4
INVOLT1
Input Voltage Phase 2 in V
1
106
U
3 / 4
INVOLT2
Input Voltage Phase 3 in V
1
107
U
3 / 4
TEMPDEG
Temperature C°
1
108
U
3 / 4
AUTONOMTIME
Autonomy Time minutes
1
109
U
3 / 4
STATUS
GENEREX UPS status
1
110
U
3 / 4
BATTVOLT
Battery Voltage V
1
111
U
3 / 4
INFREQ0
Input Frequency Hz Phase 1
1
112
U
3 / 4
INFREQ1
Input Frequency Hz Phase 2
1
113
U
3 / 4
INFREQ2
Input Frequency Hz Phase 3
1
114
U
3 / 4
CNT_PF
Powerfail Counter
1
115
U
3 / 4
(SNMPALARMS&0x1)
Alarmbit,contact legrand / Meta
1
116
U
3 / 4
(SNMPALARMS&0x2)>>1
Alarmbit,contact legrand / Meta
1
117
U
3 / 4
(SNMPALARMS&0x4)>>2
Alarmbit,contact legrand / Meta
1
118
U
3 / 4
(SNMPALARMS&0x8)>>3
Alarmbit,contact legrand / Meta
1
119
U
3 / 4
(SNMPALARMS&0x10)>>4
Alarmbit,contact legrand / Meta
1
120
U
3 / 4
(stoi(TRIMOD_STATUS)&0x8)
Alarmbit,contact legrand / Meta
1
121
U
3 / 4
(CBSER2ALARM&0x40)>>6
Alarmbit,contact legrand / Meta
1
122
U
3 / 4
(SNMPALARMS&0x80)>>7
Alarmbit,contact legrand / Meta
1
123
U
3 / 4
(SNMPALARMS&0x100)>>8
Alarmbit,contact legrand / Meta
1
124
U
3 / 4
(stoi(TRIMOD_STATUS)&0x8)
Alarmbit,contact legrand / Meta
1
125
U
3 / 4
(SNMPALARMS&0x2000)>>13
Alarmbit,contact legrand / Meta
1
