182
Take down the protective jacket of the spring.
Dismantle the guide pin.
Take down the left-half weldment of the driven wheel.
Dismantle the oil seal from the left-half part of the driven
wheel.
Check the free length of the clutch spring.
Protective jacket of the spring
The left-half weldment of the
driven wheel
Guide pin Oil seal
Free length
Right-half of the driven wheel
Left-half of the driven wheel
