Resource Pro
EMERGENCY DECOMPRESSION
The Resource Pro is a sophisticated instrument designed with capabilities that can help you to
avoid and, if necessary, manage decompression.
WARNING: See pages 47 and 48 for Special Warnings and Additional
Safety Information.
NITROGEN BAR GRAPH
The Nitrogen Bar Graph offers you a convenient way to consistently monitor how close you are
coming to the No Decompression Limit. As you use the Resource Pro and become familiar with
the Nitrogen Bar Graph, you will notice that it displays fewer segments for shorter dive times and
shallower depths. Use this feature to adjust conservatism to your diving needs.
NOTE: Use the yellow Caution Zone of the Nitrogen Bar Graph (Fig. 30a)
as a visual reference to place a wider margin of protection between you
and the No Decompression Limit.
Genesis Scuba suggests keeping the Nitrogen Bar Graph in the green No Decompression
zone during all of your dives, and that it always be in the 'green' when leaving the water.
Fig. 30 - NiBG Caution Zone
a
N
NDL
D
E
C
O
D
E
C
O
D
E
C
O
D
E
C
O
FT
