42
TAT
STOP
D
E
C
O
D
E
C
O
D
E
C
O
D
E
C
O
FT
TAT
STOP
D
E
C
O
D
E
C
O
D
E
C
O
D
E
C
O
FT
The added Penalty Time will have to be served before obtaining off-gassing credit begins again.
Once the Penalty Time is served and off-gassing credit begins, Required Stop Depths and Times
will decrease toward zero, then the Nitrogen Bar Graph will recede into the yellow Caution Zone
and the Resource Pro will revert to the No Decompression Dive Mode.
DELAYED VIOLATION MODE
Three conditions will cause the Resource Pro to enter a Delayed Violation Mode:
1. You remain above the Required Ceiling Stop Depth for 'more than 5 minutes'.
Total Ascent Time (TAT), the Stop Bar symbol, and Nitrogen Bar Graph DECO segment flash
(Fig. 39) until you descend below the Required Stop Depth.
You would then need to follow the Stop Depths and Times toward the surface until the Nitrogen
Bar Graph recedes into the yellow Caution Zone.
2. Your necessary Decompression requires a Ceiling Stop Depth between 60 feet (18
meters) and 70 feet (21 meters).
Total Ascent Time (TAT), the Stop Bar symbol, and full Nitrogen Bar Graph will flash (Fig. 40)
until you descend below the Required Stop Depth.
You must ascend to just deeper than 60 feet (18 meters), staying as close to 60 feet (18 meters) as
possible without causing Total Ascent Time (TAT) to flash. When the Required Stop Depth in-
dicates 50 FT (15 M), etc., you can ascend to, but no shallower than those depths and continue
decompressing.
Fig. 39 - Delayed Violation
(> 5 min above a Deco Stop)
Fig. 40 - Delayed Violation
(> 60FT/M Stop Required)
Flashing Flashing
Flashing
