Rocket 4D Evaporation System
52 04-7848 Issue 2-4 August 2014
Technical Data
Specifications
Evaporation vessel capacity
Dimensions includes allowance for lid opening
but not for hose and cable connections
Vacuum hose / control cable length
Dual glass coil, remote chiller
Minimum coolant temperature
Required coolant flow rate
Max coolant inlet pressure
Re-circulating chiller (remote)
50% mix: water / monoethylene glycol
Storage / transportation environment
(-10°C permissible during transportation)
10% to 80% non-condensing
10% to 80% non-condensing
Ingress protection rating
The evaporator is designed for use in a pollution
degree 2 environment (normally only
non-conductive pollution occurs).
Typical noise level is 65 dB (A) at one metre from
the evaporator during normal operation.
For the purpose of air conditioning requirement
calculations, all power consumed by the system is
dissipated as heat.
Current @ Unit Voltage (A rms)
The system must be connected to mains power supply outlets by three separate mains power cables (two to
the Rocket 4D and one to the re-circulating chiller). Refer to the Julabo User Manual for chiller power
requirements. Power cables supplied are 2 m in length and appropriate to the region to which the unit is
delivered. For 120 V systems, power cable 1 (LEAD 1 – 10 A) must be connected to inlet connector 1 (power
switch); power cable 2 (LEAD 2 – 15A) must be connected to inlet connector 2 (service panel).
Note: To prevent nuisance tripping, the mains power supplies to the evaporator should be fitted with suitably
rated type “D” (or equivalent) mains circuit breakers.
