Hose connections
Batch system
This overview shows the hose connections for a Rocket 4d Batch system; refer to the
installation instructions of the following pages.
1. Vacuum hose
2. Vacuum pump exhaust adapter
3. Pump exhaust
4. Waste solvent drain hose
5. Waste container vent hose
6. Waste solvent container
7. Coolant feed and return
8. Re-circulating chiller
9. Exhaust
1
2
3
4
5
6
7
8
9
