Appendix 4 COM communication
Hardware conditions: Connect the RS-232C ports of the two
instruments needing to be communicated by RS-232C cable, or
connect the instrument with the COM port of the computer. This
instrument provides the following options about COM status:
Connection: If you want to perform data exchanges with a computer,
please connect a standard RS-232 cable with the “COM RS232 1” port
at the rear of the instrument, and connect the other terminal with the
COM at the rear of the computer.
Please set up as per the following steps:
Baud rate: 115200, 57600, 38400, 19200, 9600
Parity check: Odd, Even, None
Working status: On, Off
Item code (Items 001~200; at most 200 items):
No.
Item Code
No.
Item Code
1
1
8
8
2
2
9
9
3
3
10
10
4
4
11
11
5
5
……
……
6
6
……
……
7
7
……
……
