2.7.12
DATA LOGGING CHAPTER 7 GEODIMETER SYSTEM 600
Pin Signal
2 Data in (RXD)
3 Data out (TXD)
7 Ground (BATT–)
8 12 V (BATT+)
Tab. 7:5 Computer connection configuration
Trig
Start of distance measurement in instrument.
Syntax: TG[<arg>]
<arg>: '<' This is default and need not to be entered.
Write
Write data into instrument. All labels that can be set by the
function key in the system can be written.
Syntax: WG,<label>=<data>
<label>: 0-109
<data>: Maximum 9 digits for numeric type labels and
maximum 16 characters for ASCII type labels.
When "REG-Key" is selected data corresponding to the actual
output table will be transmitted when the REG-key is pres-
sed.
The "Slave" -mode setting means that data are automatically
transmitted every time an instrument measurement is com-
pleted without needing to press the REG-key.
Hardware connection serial (RS-232/V24)
Use the multifunctional cable (Part no 571 202 188/216)
together with the computer adapter (Part no 571 202 204) to
connect the Keyboard unit to a computer via the external
battery (Part no 571 202 194) or power supply.
