1.1.14
INTRODUCTION CHAPTER 1
GEODIMETER SYSTEM 600
Key functions
ON / OFF key
Turns power on when pressed once, turns power off when
pressed again. If no key is pressed within 60 seconds from
power on the instrument automatically turns off.
When the instrument is turned on again within 2 hours from
latest use you will get the question "Continue Yes/No?".
If you answer yes to this question the Geodimeter returns to
the mode that was current when the Geodimeter was turned
off.
All the instrument's parameters and all functions, such as
instrument height, signal height, coordinates, bearing, dual
axis compensation, etc. are stored in the instrument for two
hours. If you answer "NO" the Geodimeter is reset and some
parameters are lost, e.g. IH, SH.
If batlow occurs no measurements can be carried out. The
next time (within 2 hours) the instrument is turned on you
will be prompted "Powered off by battery low?". Answer yes
to return to the mode that was current before battery low.
Note that no measurements can be carried out before
replacing the drained battery or connecting an external
battery to the instrument.
Battery condition
You can see the current capacity of the connected battery at
the end of the first row in the display. As the battery
becomes drained the battery symbol will change from full to
empty. Note that this function depends on the battery
condition and on the charging method and should only be
regarded as a coarse indication.
Batlow
Total
Station
PWR
Powered off by
operator
Continue Yes/No?
Battery
condition
