12.1 Packing List

• GV-PTZ010D

• Mounting Base

• Mounting Cover

• Wall Mount Bracket

• Screw Anchor x 3

• Long Screw x 3

• Short Screw x 3

• Round Screw x 3

• GV-PTZ010D Software CD • Washer x 3

• GV-PTZ110D / GV-

PTZ010D Quick Start Guide

• GV-NVR Quick Start Guide

• GV-NVR Software DVD • Terminal block

Note: Power adapter can be purchased upon request.

138

Default Chapter12
- Table of Contents12
- Naming and Definition24
- Device Description25
- Options25
- Note for Connecting to GV-System28
- Note for Recording29
- Note for Adjusting Focus and Zoom30
- Note for Installing Camera Outdoor31
- Note for Closing the Camera Cover33
- Note for USB Storage and Wifi Adapter34
Chapter 1 Introduction35
- System Requirement35
Chapter 2 Box Camera36
