GeoVision GV-MFD320 User Manual

Fixed IP Dome
16
16.4.2 In-Ceiling Mount
Figure 16-10
1. Follow step 2 in the 16.4.1 Hard-Ceiling Mount to remove the housing
cover and take out the camera body.
2. Paste the supplied sticker onto a desired location on the ceiling and
cut a circle on the ceiling along the edge of the sticker.
3. On the mounting plate, locate the 3 holes labeled as 1 and insert the
3 copper pillars from the back side.
Figure 16-11
229
