Models Adjustment Screws

Mini Fixed Dome

Lens Screw

Focus Ring

Mini Fixed Rugged

Dome

Lens Screw

Focus Ring

Note:

1. The adjustment screws of Box Camera may vary for different

models.

2. To focus GV-MFD and GV-MDR, loosen the lens screw first and

slowly adjust the focus ring. Some models may need a T6 screw

driver to loosen the camera lens. If you have a problem of

obtaining this type of screw driver, please contact our overseas

offices for further assistance.

268
