No. Name Description

5 Log Tab

Displays up to 100 event entries of the GV-

SDCardSync Utility. Once the entries are full,

recycling will start from the oldest file.

6 Storage Space

Shows the storage space of the designated hard

drive.

Note:

1. The synchronization time is recorded according to the system time

of the GV-IP Camera.

2. The logs are deleted once the GV-SDCardSync Utility is re-

activated.
