Getting Started 1-7
Taking a Look at the Computer
NOTE:
z Depending on the model you purchased, the appearance of your
computer may not be exactly the same as those shown in this manual.
z You need to open the protective covers to access the connectors. When
not using a connector, make sure to close the cover completely for
water- and dust-proof integrity. (Engage the locking mechanism if the
cover is designed with such mechanism.)
Front Components
Ref Component Description See Also
n
Top Cover Latch Locks the top cover. P. 1-5
o
WWAN 3G
Antenna
Should be pulled out for reception of
mobile telecommunications signals.
P. 2-30
p
Handle Provides a convenient way to carry the
computer.
To Next Page
