Getnet GR-724W User Manual

96
Popula Applications This section lists the more popular applications that
(7): require multiple connections. Select an application
from the Popular Applications selection and click
‘Add’ to save the setting to ‘Current Trigger-Port
Table.’
Add (8): Add the setting to the ‘Current Trigger-Port Table.’
Reset (9): Click ‘Reset’ will clear all above setting and you
can set up again.
Current Trigger-Port All the settings for the special applications will be
(10): listed here. If you want to remove some Special
Application settings from the " Current Trigger-Port
Table", select the Special Application settings you
want to remove in the table and then click "Delete
Selected". If you want remove all Special
Appliacation settings from the table, just click
"Delete All" button. Click "Reset" will clear your
current selections.
Delete (11): Please select a special application by clicking
the ‘Select’ box of the mapping, then click ‘Delete
Selected’ button to remove the setting. If there’s no
setting here, this button will be grayed out.
Delete All (12): Delete all settings existed in trigger port table.
Reset (13): Unselect all settings.
Note: Only one LAN client can use a particular special application at a
time.
After you finish with all settings, please click ‘Apply’ (14) button and the
following message will be displayed on your web browser:

Getnet GR-724W Specifications

General

VPN support	IPSec/PPTP
Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	11n:14±1.5dBm 11g:14±1.5dBm 11b:18±1.5dBm 300Mbps OFDM, 10% PER, ‐ 65±2dBm 54Mbps OFDM, 10% PER, ‐ 73±2dBm 11Mbps CCK, 8% PER, ‐ 86±2dBm
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	-
WLAN data transfer rate (max)	300 Mbit/s
Interface	WAN, LAN, WiFi
Input current	0.5 A
Input voltage	12 V
Number of users	253 user(s)
Dimensions (WxDxH)	163 x 112 x 30 mm
USB ports quantity	0
Supported protocols	WAN Protocol: PPPoE /Static IP/ PPTP /Dynamic IP /L2TP / Telstra Big Pond
Compatible operating systems	Windows Vista/7
NAT functionality	NAT/NAPT IP Sharing
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Ethernet LAN (RJ-45) ports	4
Flash memory	4 MB
Certification	CE, FCC
Internal memory	16 MB
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black

Weight and Dimensions

Weight	- g
