Chapter IV: Appendix
4-1 Hardware Specification
Product Wireless 300M Broadband Router
Model Name: GR-724W
Main Chipset RTL8196B + RTL8192SE
Flash and SDRAM 4MB Flash + 16MB SDRAM
Standard IEEE 802.11b/g/n
Frequenc
y Band
2.4000~2.4835GHz (Industrial Scientific
Medical Band)
Modulation OFDM with BPSK, QPSK, 16QAM, 64QAM (11n)
OFDM with BPSK, QPSK, 16QAM, 64QAM (11g)
DSSS with BPSK, QPSK, CCK (11b)
Data Rate 11n (20MHz): MCS0-15, up to 144Mbps
11n (40MHz): MCS0-15, up to 300Mbps
11g: 54/48/36/24/18/12/9/6
11b: 11/5.5/2/1Mbps
auto fallback
Security WEP 64/128, WPA, WPA2, IEEE 802.1x
Antenna 3dBi Dipole Antenna x 2(2T2R)
Transmit Power 11n:14±1.5dBm
11g:14±1.5dBm
11b:18±1.5dBm
Receive Sensitivity 300Mbps OFDM, 10% PER, -65±2dBm
54Mbps OFDM, 10% PER, -73±2dBm
11Mbps CCK, 8% PER, -86±2dBm
Dimension 30(H) x 157(W) x 127(D) mm
Temperature
Operating: 32~104˚F (0~40˚C)
Storage: -4~140˚F (-20~60˚C)
Humidity Operating: 10-90% (NonCondensing)
Storage: Max.95% (NonCondensing)
