MDE-4699L Applause™ Media System Installation, Service, and Parts Manual · June 2017 Page 4-15
Registering Applause Media System Start-up
Adjusting Volume Level
To adjust the volume level, proceed as follows:
1 At the CRIND device, swipe the CRIND diagnostic card.
Figure 4-17: Swiping CRIND Diagnostic Card
2 Press 1 for the Main Menu.
3 Press 2 for Device Config.
4 Press 2 for Audio Settings.
5 Press 1 for side 1 or press 2 for side 2.
6 Set the volume level by either entering the required number or using the up or down softkey
functions.
Note: It is recommended that you start with a volume setting of 93.
7 Press CANCEL to end the session.
