MDE-4699L Applause™ Media System Installation, Service, and Parts Manual · June 2017 Page 1-3
Required Tools and Equipment Introduction
Required Tools and Equipment
The following tools are required for the installation and service of the Applause Media
System:
• Laptop loaded with the latest software for CRIND
®
and dispensers (for software
do
wnloading procedures, refer to MDE-3921 Laptop Tool User Reference Guide).
•Ethernet
®
Cable [crossover and standard (for connecting the laptop to Long Range
Ether
net (LRE) switch)]
• Universal Serial Bus (USB) to Ethernet Adapter
• Standard Socket Set (SAE)
• Phillips
®
and Flat-blade Screwdrivers
• Electric Drill (to be used inside the site, not at t
he dispenser)
• Drill Bits for various wall types (masonry,
wood, and sheetrock)
• Mounting Anchors and/or Screws (to hold 10 pounds, not supplied)
• Electrostatic Discharge (ESD) Ground Strap
• Keyboard and Monitor (for diagnostics)
• Software Installation USB Drive or CD-ROM
• CRIND Diagnostic Card (Q12534-170)
Note: A USB keyboard is preferred. A PS/2 keyboard can also be used. If a PS/2 keyboard is
us
ed, the syste
m to which it is attached needs to be rebooted.
Common Terms
Term Description
10 BASE-T A method for implementing an Ethernet using Unshielded T
wisted-pair (UTP) wiring that is defined in
American National Standards Institute (ANSI)/Institute of Electrical and Electronics Engineers (IEEE)
802.3. The first number may vary and corresponds to the data rate (10 Megabits per second in this
case).
Ethernet
Cable
A specification for UTP wiring used in a Local Area Network (LAN) and defined in
T
ele
communications Industry Association/Electronic Industries Alliance (TIA/EIA) 568 B.
Ethernet Network architecture for a LAN that defines the communication medium a
nd messages sent on that
medium.
Forecourt Area at a C-Store or gasoline station where CRIND devices/dispensers are located.
LAN Communications system that connects various pieces of electronic e
quipme
nt within an office or
building.
Telco Telephone company
Telnet Terminal Emulation Network
Twisted-pair Two insulated copper wires twisted around each other to redu
ce induction (interfer
ence) from one
wire to the other.
Related Documents
Document
Number Title GOLD
SM
Library
FE-363 Field Wiring Diagram Encore 500 and Encore 700 Dispensers
(M
07555 Power Supply Only)
• Encore and Eclipse
®
• Encore and Eclipse Installers
• Field Wiring Diagrams
MDE-3921 Laptop Tool User Reference Guide • Encore and Eclipse
• Encore and Eclipse Installers
